Product Details:
|
| Name: | R17mm 24V LED COB Chips 1919 Series Ra80 3000K 4000K 6500K | Size: | 19x19mm |
|---|---|---|---|
| CCT Color: | 3000K, 4000K, 6500K | Power: | 16W, 20W |
| Les: | R17mm | Input Voltage: | 24V |
| Highlight: | 24V LED COB Chips,No Glare Light LED COB Chips |
||
R17mm 24V LED COB Chips 1919 Series Ra80 3000K 4000K 6500K
Design Advantage of R17mm 24V LED COB Chips 1919 Series Ra80 3000K 4000K 6500K:
1,No glare light
2,Color consistance
3,Low life decay
4,Low thermal resistance
5,High CRI 80/90/95+
6,High standard raw materials proovide
Product Specifications
| Models | HY-CAS19XW-P16-17 | HY-CAS19XW-P16-17 | HY-CAS19XW-P20-17 | HY-CAS19XW-P20-17 |
|---|---|---|---|---|
| Electronic power | 16W | 16W | 20W | 20W |
| Color temperature | WW: Warm white=2700-3000K NW: Neutral white=4000-4500K PW: Pure white=6000-6500K |
WW: Warm white=2800-3000K NW: Neutral white=4000-4500K PW: Pure white=6000-7000K |
WW: Warm white=2700-3000K NW: Neutral white=4000-4500K PW: Pure white=6000-7000K |
WW: Warm white=2700-3000K NW: Neutral white=4000-4500K PW: Pure white=6000-7000K |
| Luminous efficiency | 120-140lm/w | 110-120lm/w | 120-140lm/w | 110-120lm/w |
| Working voltage | 24V | 24V | 24V | 24V |
| Circuit | 8S4P | 8S4P | 8S5P | 8S5P |
| Size | 19*19mm | 19*19mm | 19*19mm | 19*19mm |
| LES(Diameter) | R17mm | R17mm | R17mm | R17mm |
| View angle | 120DEG | 120DEG | 120DEG | 120DEG |
| CRI | >80 | >80 | >80 | >80 |
| SUBSTRATE | MIRROR ALU | MIRROR ALU | MIRROR ALU | MIRROR ALU |
| Working current | 600mA | 600mA | 750mA | 750mA |
