Product Details:
|
| SIZE: | 500*8mm/5000*8mm | Chip Brand: | Sanan |
|---|---|---|---|
| CCT: | 2700K-6500K | Color: | White |
| Lifespan: | 50000h | Lumen Effieciency: | >120lm/w |
| High Light: | 41.6mm Cuttable COB LED Strip Lights,384leds/M COB LED Strip Lights,FPC Cob Flex LED Strips |
||
COB strip light COB soft light bar COB flexible strip light flip chip COB strip light
 |
Specification | Light bar parameters |
| Brand | Huangtai | |
| Type | HY-COB12V24V-8-C384 | |
| LED QTY | 384 LEDs/m | |
| Chip manufacturers | Sanan/Epister/Customized | |
| CRI | Ra90 | |
| Input voltage | 12v/24v | |
| Power | 9-10w/m | |
| Luminous officiency | 100-120lm/m | |
| Luminous brightness | 900-1200LM/W | |
| Board width | 8mm | |
| Color temperature | 3000k/4000k/6000k | |
| Cuttable length | 41.6mm | |
| Working lifetime | 50000h | |
| Working temperature | -20℃-40℃ | |
| Warranty | 3 years |
Advantages of the new soft light bar
1.Widely used, easy to install and maintain, long service life
2.Very flexible, easy to bend into different shapes, various white light options
3.COB Design, with more chips on PCB, more even light.
4.Up to 512 chips on 1 meter PCB, only 2.0mm space between chips.
5.Cuttable at every 25-63mm length. Form a circuit without affecting other circuites.
6.Efficiency up to 100Lm/W.
7.Ra 90 also available.
8. Can be customized according to customer requirements
Installation Ways
* The max running length is 5 meters, for over 5 meters please connect in parallel.
* Make sure of the total watts of COB Strip lights is less than 80% of the power supply's
max output.
* Match the polarities according to the mark ('+' and '-') in the PCB while connecting.
Application
1. Residential lighting,
2. Hotels, KTV and other places of entertainment decorative lighting.
3. Furniture decoration lighting
4. Display cabinet, jewelry cabinet counter lighting
5. Lighting of concealed parts of corridor stairs
Company informaton
FAQ:
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than
A: Low MOQ, 1pc for sample checking is available
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
A: Yes, we offer 2-5 years warranty to our products.
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.
Secondly, during the guarantee period, we will send new lights with new order for small quantity. For
defective batch products, we will repair them and resend them to you or we can discuss the solution i
ncluding re-call according to real situation.
